The following is the installation instructions: Use the correct part number as listed in the application catalogue ,Do not use sensor if i has been dropped ,Remove protection cap just prior to installation;
Firstly install sensor body ensuring lead wire is not twisted or bent , Do not use impact wrench or socket type wrench to install sensor ,M18 sensors - install finger tight then 1/2-3/4 turn with a wrench (35-45Nm) ;
Then connect and route lead wire as originally installed , Do not allow lead wire to touch exhaust manifold or any other hot component ,Do not apply any substances (especially oil or grease) to connector sensor ,Do not use leaded fuels,silicone or metal based additives.
- Wire Harness Length: 18.9
- Sensor Type: Oxygen Sensor
- Manufacturer Warranty: 1 Year
Make Model Engine Year Notes
CHEVROLET COLORADO L4-2.8 2006 Upstream
CHEVROLET COLORADO L4-2.9 2012-2007 Upstream
CHEVROLET COLORADO L5-3.5 2006 Upstream
CHEVROLET COLORADO L5-3.7 2012-2007 Upstream
CHEVROLET TRAILBLAZER L6-4.2 2009-2007 Upstream
CHEVROLET TRAILBLAZER L6-4.2 2006 Upstream
CHEVROLET TRAILBLAZER EXT L6-4.2 2006 Upstream
GMC CANYON L4-2.8 2006 Upstream
GMC CANYON L4-2.9 2012-2007 Upstream
GMC CANYON L5-3.5 2006 Upstream
GMC CANYON L5-3.7 2012-2007 Upstream
GMC ENVOY L6-4.2 2009-2007 Upstream
GMC ENVOY L6-4.2 2006 Upstream
GMC ENVOY XL L6-4.2 2006 Upstream
