Channel of RF circuit board: 24
Probe frequency and scan depth, head radiuswidth, scan angle(convex); Convex head 3 5MHz/5MHz, 90/160/220/305mm, 45mm, 50*
Convex head by phased array(cardiac) scan mode: 3.5MHz/5MHz,
90/160/220/305mm, 45mm, 80*
Linear head 7.5MHz/10MHz, 20/40/60/100mm, 40mm
Image Adjust: BGain, TGC, DYN, Focus, Depth, Harmonic, Denoise, Color Gain, Steer, PRF
Cineplay. auto and manual, frames can set as 100/200/500/1000
Puncture assist function: the function of in-plane puncture guide line, out-of-plane puncture guide line, automatic blood vessel measurement.
Battery working time: 3.5 hourslaccording to whether keep scan)
Battery charging : by wireless charging, 2 hours
Dimension: L156xW60xH20mm
Weight: 260g
Wif type: 802.11g/20MHz/5G/450Mbps
Working system: Apple ios and Android, Windows
Specifications:
Scanning mode:
Electronic array
Probe Type:
Consist by Convex and Linear, Convex with mode of Phased array
Display mode:
B, B/M, B+Color, B+PDI, B+PW
Probe element: 96
